Elegant high-end tube phono pre-amplifier with an ultra slim design!
E-Glo S – is a hybrid phono preamplifier that utilizes ECC83 tubes (twin triode) in the first and second gain stages. In order to get higher gain and lower noise, we use in the first stage a cascade connection of tube with two parallel-connected low-noise J-FET transistors.
The RIAA curve is equalized and fully passive and split into two steps, which allows to us achieve perfect impedance matching between the gain stage and equalization block. The E-Glo S preamplifier doesn’t have any global feedback. It has a massive aluminum chassis, with the ability to adjust the impedance, capacity, and gain. It has subsonic filter with mild effect, which doesn’t affect audible frequencies in a negative way.
A very important part is the advanced power supply that uses anode voltage regulation and a well-filtrated voltage. Filtration is in three steps; the result is a perfect S/N ratio for an undisturbed musical experience.
Available with Macassar (wood) or Gloss Black side panels.
E.A.T. E-GLO S TUBE PHONO PREAMPLIFIER TECHNICAL INFORMATION
INPUT IMPEDANCE | MC 10,25,50,75,100,1000 Ohm |
---|---|
LOAD CAPACITY | 50,100,150,200,270,320,420 pF |
OUTPUT IMPEDANCE | 100 ohms |
LOAD CAPACITY | 50,100,150,200,270,320,420 pF |
GAIN MM | 45 dB |
GAIN MC | 45,50,55,65,70 dB |
RIAA ACCURACY | within 0.5dB 20Hz – 20kHz |
SUBSONIC | 18 dB / Octave |
INPUT | RCA |
OUTPUT | RCA |
POWER SUPPLY | DC18V/1 |
DIMENSIONS W × H × D | 435 × 90 × 270 mm |
