Revel C426Be Center Channel Loudspeaker

  • Sale
  • Regular price $4,500.00


Revel C426Be Center Channel Loudspeaker

The Revel C426Be joins the award-winning PerformaBe series as a high-performance center channel loudspeaker for use in a multichannel home theater environment. As part of the PerformaBe loudspeaker line, the C426Be includes a 1-inch (25 mm) beryllium tweeter driven by massive 85 mm dual ceramic magnets. The powerful tweeter and 5th-generation ceramic-coated, cast-aluminum Acoustic Lens waveguide seamlessly integrate with the directivity of the companion midrange driver resulting in greater efficiency, improved dynamic range, reduced distortion, and increased power handling compared to aluminum or titanium tweeters.

 Features

  • 1" beryllium dome tweeter
  • 5th-generation Acoustic Lens waveguide
  • Deep ceramic composite (DCC) cone midrange and woofers
  • High-order crossovers with film capacitors and air-core inductors
  • Magnetically attached grilles

Specifications

Type: 3-way quadruple 6.5" center channel loudspeaker
Low-frequency transducer: Four 6.5" (165 mm) deep ceramic composite (DCC) aluminum cones with cast frames
Midrange transducer: 5-1/4" (130 mm) deep ceramic composite (DCC) aluminum cone, with cast frame
High-frequency transducer: 1" (25mm) beryllium dome with Acoustic Lens wave guide
Frequency response: 46 Hz-40 kHz (-6 dB)
Low-frequency extension: 37 Hz (-10 dB) 46 Hz (-6 dB) 52 Hz (-3 dB)
Nominal impedance: 8 ohm
Sensitivity (2.83V/1m): 90 dB
Crossover frequencies: 210 Hz, 2.1 kHz
Enclosure type: Bass-reflex via 2 rear-mounted ports
Inputs: Dual gold-plated binding posts with shorting straps
Dimensions with grille (HWD): 10.4" x 38.6 " x 14" (263 mm x 979.7 mm x 358 mm)
Weight: 61 lb (27.7 kg)
