PrimaLuna EVO 200 Tube Preamplifier
Compare PrimaLuna construction to any other brand, at any price. You'll be amazed.
|Inputs||4x Stereo RCA
Stereo HT Bypass
|Outputs||2x Stereo RCA
Stereo RCA Tape Out
|Freq. Response||4Hz-85kHz +/- 3dB|
|THD||< 0.5% @ 2V|
|S/N Ratio||93 dB, 98dBA|
|Power Consumption||51 watts|
|Standard Tube Complement||4 - 12AU7
2 - 5AR4
|Dimensions (WxHxD)||14.4" x 8.1" x 15.9"|
What PrimaLuna EVO 200 Tube Preamplifier owners think:Read Owner Reviews »
(Optional) Internal Moving Magnet Phonostage
|Distortion & Noise||-83dB|
|Suggested Min. Cartridge Output||2.0 mV|
EVO internal phonostage connects directly to one of the existing line inputs on your PrimaLuna EvoLution series Integrated Amp or Preamplifier. No extra plugs or cables required. Uses Surface Mount Technology implementation for the shortest signal path and reduction of parasitic capacitances and inductance.
Made in Holland to ISO 9001 standards, boasting selected components for the best sound quality. Miniature film capacitors, minimelf resistors, and a superior op-amp for lowest noise, highest speed, and robust drive. Low impedance electrolytics and a super low noise power supply results in a turntable experience with goose bumps!
Suitable for both moving magnet and high-output moving coil cartridges. Can be installed any time (requires basic soldering skills) or installed at time of purchase (no installation fee).
Dual Toroidal Power Transformers
One of the best headphone amps in the world. And the only amp that lets you listen with either the warmth of Triode or the wide-bandwidth of Ultra-linear operation at the push of a button! Most tube integrated amps and preamps use a solid state op-amp chip for running headphones. Stand alone tube headphone amps will vary in quality like any other tube amp. Headphones are simply small speakers that require less power. Some amps will use smaller output tubes that groan to have enough dissipation to run power-hungry planar headphones. Other brands, including those costing $5,000 or more like Mal Valve, will use larger output tubes, then use a voltage divider network to drop the power down to an acceptable level for headphones. This is how we do it. We simply took advantage of the fact that we make the best tube integrated amplifiers. Now you don't have to pay for a separate state of the art headphone amp. PrimaLuna integrateds are the favorite of owners who use everything from Audeze to Hifiman to Sennheiser!
In the world of preamps, experts agree that tube rectification is the gold standard. It’s quieter than solid state rectification, dropping the noise floor. And it offers the most natural, textured, and vibrant presentation because the circuit is now pure tube. But because it is expensive to implement, you’ll only find it in the top of the line models typically costing $10,000 or more. Finding a preamp using one rectifier tube is sweet. PrimaLuna goes even further using two 5AR4 rectifier tubes in a dual-mono design to present your music with a three-dimensionality that will give you goosebumps.
Japanese Alps Blue Velvet Potentiometer
The best tube preamps use analogue volume controls. Not volume control chips. Look inside the most well-known brand of tube preamps and you will see a chip called a DS1666-10 Digital Resistor IC. At Primaluna, we understand the temptation to use this chip as they cost $4 each (half that in quantity!). The preamp will sound fine and be quiet, but true to “chips” it will add an electronic “sheen” to the sound. PrimaLuna prefers analogue. And we use the Gold Standard in motorized potentiometers: The iconic Alps Blue Velvet. Why? Because they track perfectly, stay quiet, and don’t sound like chips!
Superquiet Line Inputs
Input selector switches leak noise and signals from other sources, as they never turn off the other inputs completely. And, they deteriorate with age, requiring the use of cleaners. Many are mounted on the front panel requiring long runs of wires to the back panel inputs. These wires pick up stray noise from RF and EMI.
PrimaLuna has a better way. Instead of a switch, input selection is done using premium quality sealed relays mounted in the rear where you plug in your components. When an input is selected, that relay closes giving you the best connection possible. All the other relays are left open, so noise and signals from other sources can’t leak in. The signal path is now almost non-existent, so there are no wires to pick up noise.
You spend a lot of money on interconnects. So why have the signal go right from the RCA jacks or speaker terminals into circuit boards with copper traces so thin you can hardly see them? What’s high-end about that?
PrimaLuna employs Point to Point Wiring on all products. The entire signal path, including resistors and capacitors, is painstakingly hand wired with heavy-gauge cable by craftsman.
No Internal DAC / No Internal Phonostage (sub of p2p wiring)
Never buy an integrated amp with an internal DAC. Why? Because digital changes, and history shows that integrated amps with “old” digital become unwanted and have almost no resale value.
Built in phonostages are “throw in” and are rarely good quality because manufacturers assume 90% of buyers won’t use them. The external phonostage market is very competitive. You can get something much better for as little as $200, and buy one that actually meets your cartridges needs and YOUR budget.
Expensive and exotic preamps always use a dual-mono design to achieve a level of imaging not possible otherwise. Most manufacturers don’t employ dual-mono because of expense. It requires two power transformers, double regulation circuits, and in fact….everything is double. In effect, dual-mono means building two discrete and separate preamps into one box. It is so expensive to build, it’s a rarity even at the highest price points. All PrimaLuna preamps are dual-mono for the ultimate in stereo imaging and a sense of space that goes on forever.
A preamplifier is typically not required to add any gain to your system when you are using it. It is usually lowering gain from the source you are listening to. The number one complaint from audiophiles about preamp performance is noise. So why is it that so many manufacturers design preamps with 20 to 27dB of gain? And you wonder why there is "hiss", and why tubes go noisy or microphonic? PrimaLuna preamps use SmartGain. With a gain specification of only 12dB, you will find your PrimaLuna preamp is as quiet as a church mouse. If tubes are less than perfect, you may never know it because they are not amplifying as "loud". High efficiency speaker owner's rejoice!
Another exclusive PrimaLuna feature is PerfectMatch, a circuit designed to present a perfect 100K ohm impedance to your source components. This is vitally important especially for tube source components, such as phonostages and DACs to sound their very best.
PrimaLuna Preamp Feature Comparison
|Swiss Made Wiring||✔||✔|
|DuRoch Tinfoil Capacitors||✔||✔|
|AC Offset Killer||✔||✔|
|Dual Mono Topology||✔||✔||✔||✔|
|Vacuum Tube Rectified||✔||✔||✔||✔|
|Remote Control||Full Remote||Full Remote||Slim Remote||Slim Remote|
|Custom Potted Toroidal Power Transformers||✔||✔||✔||✔|
|ALPS Blue Velvet Potentiometer||✔||✔||✔||✔|
|Home Theater Pass-Through||✔||✔||✔|
