My Sonic Lab Stage 1030 Step-Up Transformer
Step-up transformer with exclusive Hi-μ core for ultra-low impedance moving coil cartridges.
Low-impedance moving coil cartridges use smaller windings and have less moving mass for great detail and speed. However, the low output means that they need a lot of gain, which can add noise and grain. The step-up transformer (SUT) solves this, but needs to be of extremly high quality. The Stage 1030 uses a high-mu core to create tremendous current density and stability for the most realism you've ever heard.
Specifications
Gain: 26 dB
Input Impedance: 0.3 Ω to 6 Ω
Load Resistance: 47 kΩ to 100 kΩ
Dimensions (WHD): 5.91" × 2.56" × 4.33"
