McIntosh MC462 Stereo Power Amplifier

450 Wpc stereo power amplifier with Quad Balanced circuitry, Autoformers, and 3 dB of dynamic headroom

The McIntosh MC462 is a high-power stereo amplifier delivering 450 Wpc into 2-, 4-, or 8-ohm loudspeaker loads. Dedicated McIntosh Autoformers on each channel allow the amplifier to provide its full rated output regardless of which supported impedance is connected, making the MC462 suitable for a wide range of demanding loudspeakers.

Compared with the preceding MC452, the MC462 increases filter capacity by nearly 50%, raising dynamic headroom from 1.8 dB to 3 dB. The additional energy storage helps the amplifier accommodate large musical peaks while also contributing to improved low-frequency performance.

The MC462 uses McIntosh’s Quad Balanced circuit architecture to reduce noise and distortion within the amplification stages. Four Monogrammed Heatsinks are coupled to the high-current output transistors for efficient thermal management, while Power Guard monitors the signal to prevent clipping and Sentry Monitor protects the output stage against unsafe operating conditions.

Balanced and unbalanced outputs provide additional system flexibility, allowing the signal to be passed to another amplifier for bi-amping or tri-amping, sent to a secondary system, or routed to a powered subwoofer. The amplifier is built on a polished stainless-steel chassis and retains McIntosh’s black glass front panel, aluminum handles, illuminated logo, and pair of fast-responding blue watt meters.

Features

450 Wpc Into 2, 4, or 8 Ohms

Dedicated McIntosh Autoformers allow each channel to deliver the full rated 450 W into 2-, 4-, or 8-ohm loudspeaker loads, providing consistent rated output across a broad range of speaker impedances.

3 dB Dynamic Headroom

Increased filter capacity gives the MC462 3 dB of dynamic headroom, providing additional short-term power for musical peaks and improving the amplifier’s ability to reproduce large changes in level without clipping.

Quad Balanced Circuitry

McIntosh’s Quad Balanced topology uses complementary amplifier sections to cancel noise and distortion components within the signal path while providing the current capability required for high-power operation.

Power Guard

Power Guard continuously compares the amplifier’s input and output signals and adjusts the input when necessary to prevent clipping that could otherwise produce harsh distortion or damage loudspeakers.

Sentry Monitor

Sentry Monitor provides fuse-less short-circuit protection for the output stage, disengaging it if current exceeds safe operating limits and automatically restoring operation when conditions return to normal.

Monogrammed Heatsinks

Four McIntosh Monogrammed Heatsinks are connected to the high-current output transistors to provide efficient thermal management and help reduce thermal equilibrium lag.

Flexible System Connections

Balanced and unbalanced outputs make it easier to add another amplifier for bi-amping or tri-amping, feed a second audio system, or connect a powered subwoofer when additional preamplifier outputs are not available.

Solid Cinch Speaker Binding Posts

McIntosh Solid Cinch binding posts provide secure speaker-cable connections and are gold-plated to resist corrosion.

Power Control

McIntosh Power Control allows compatible components to receive coordinated power-on and power-off commands as part of a complete McIntosh system.

What’s Included

• McIntosh MC462 Stereo Power Amplifier
• Remote control
• AC power cord
• Owner’s manual

Specifications

Type: Solid-state stereo power amplifier

Channels: 2

Power Output: 450 Wpc into 2, 4, or 8 ohms

Rated Power Band: 20 Hz–20 kHz

Frequency Response: 20 Hz–20 kHz, +0/–0.25 dB; 10 Hz–100 kHz (+0/–3 dB)

Total Harmonic Distortion: 0.005%

Signal-to-Noise Ratio: 122 dB below rated output

Dynamic Headroom: 3 dB

Damping Factor: Greater than 40, wideband

Circuit Configuration: Quad Balanced

Output Type: Autoformer

Balanced Inputs: 2

Remote Power Control: Yes

Output Meters: Yes

Meter Light Switch: Yes

Speaker Connections: Solid Cinch speaker binding posts

Front Panel: Glass with handles

Illumination: Direct LED

Chassis: Polished stainless steel and black painted steel

Dimensions (H × W × D): 9-7/16" × 17-1/2" × 22-1/2" (23.97 × 44.45 × 57.2 cm), including feet, front panel, handles, and cables

Weight: 115 lb. (52.3 kg)
