Arcam SA10 Integrated Amplifier
The design of the HDA range draws upon all of Arcam’s experience as one of the UK’s most respected audio companies, to produce Arcam’s best performing range of audio products yet.
The SA10 is a 50 W class A/B amp with an onboard MM phonostage and DAC. Note, there is no streamer, the Ethernet port is for monitoring and amp control only.
Features
- Extremely efficient class A/B amplification
- 50W of power per channel
- 5 analog inputs including phono
- 3 digital inputs
- 32-bit DAC,Sabre ESS9016K2M
- Full I/P control
Specifications
Continuous power output (8 ohm, 4 ohm): 50 W, 85 W
Phono (MM) input
Input sensitivity (1 kHz): 5 mV
Input impedance: 47 kΩ + 100 pF
Line inputs
Input impedance: 10 kΩ
Digital inputs
DAC chip: ESS9016K2M
Supported sample rates (optical, coaxial): 32-96 kHz, 32-192 kHz (16-24 bit)
Bit depth 16-bit – 24-bit
Preamp output
Output impedance: 230 ohm
Headphone output
Max output (into 600 ohm): 5 Vrms
Output impedance: 1 ohm
Load range: 16 - 2,000 ohm
Dimensions (WHD): 17" x 3.4" x 12.2" (433 mm x 87 mm x 310 mm)
Weight: 18.5 lb
Supplied accessories: Power cord, remote control, 2 x AAA batteries
