ARCAM A50 Signature Integrated Amplifier

Dual-mono class-G amplification with advanced digital and analog connectivity

The ARCAM A50 Signature celebrates 50 years of ARCAM amplification expertise with the company's most advanced implementation of class-G technology to date. Designed in Cambridge, UK, this high-performance integrated amplifier combines 150 W per channel into 8 ohms with a fully dual-mono architecture, sophisticated digital conversion, and a newly developed class-A phonostage for both moving magnet and moving coil cartridges.

The A50 Signature is ARCAM's first dual-mono class-G integrated amplifier. Each channel operates as a self-contained module with independent transformer windings, dedicated power regulation, reservoir capacitors, a class-G lifter stage, and its own output-stage heatsink. This architecture minimizes interference between channels while delivering exceptional channel separation, low noise, and the dynamic capability needed to control demanding loudspeakers.

Class-G amplification combines the sonic advantages of class-A operation at lower output levels with additional power supply rails that engage when the music demands greater output. The A50 Signature takes this approach further with its independently powered channels, delivering 150 W per channel into 8 ohms and 220 W per channel into 4 ohms.

Digital sources benefit from a premium ESS ES9039Q2M DAC, with USB-C connectivity supporting resolutions up to 32-bit/384 kHz. HDMI eARC provides a convenient connection to a compatible television, while additional digital inputs accommodate CD transports, streamers, and other components. The redesigned analog circuitry includes a class-A MM/MC phonostage, allowing a wide range of turntables and cartridges to connect directly without an external phono preamplifier.

Wireless connectivity is equally comprehensive. Bluetooth 5.4 supports Snapdragon Sound, aptX Lossless, and Auracast, while both wired and wireless headphone listening options provide additional flexibility. Together with its redesigned volume control circuitry and extensive source connectivity, the A50 Signature offers a complete high-performance amplification solution for both traditional and modern music systems.

Features

• ARCAM's first dual-mono class-G integrated amplifier
• 150 W per channel into 8 ohms and 220 W per channel into 4 ohms
• Independent transformer windings, power regulation, reservoir capacitors, class-G lifter stages, and output-stage heatsinks for each channel
• Newly designed class-A MM/MC phonostage
• ESS ES9039Q2M DAC with support for up to 32-bit/384 kHz digital audio via USB-C
• HDMI eARC for connection to compatible televisions
• Three stereo RCA analog inputs
• Redesigned volume control circuitry
• Bluetooth 5.4 with Snapdragon Sound, aptX, aptX HD, aptX Lossless, and Auracast
• Bluetooth audio reception and transmission for wireless listening
• Dedicated headphone output for wired listening
• Designed in Cambridge, UK
• Plastic-free packaging

What's Included

• ARCAM A50 Signature Integrated Amplifier
• Power cord
• Remote control with two AAA batteries
• Quick Start Guide
• Important Safety Instructions

Specifications

Amplifier Type: Dual-mono class-G

Continuous Power Output (8 Ohms, 20 Hz–20 kHz, 0.5% THD): 150 W per channel

Continuous Power Output (4 Ohms, 1 kHz, 0.5% THD): 220 W per channel

Harmonic Distortion (80% Power, 8 Ohms, 1 kHz): 0.002%

Analog Inputs: 3 stereo RCA pairs

Analog Signal-to-Noise Ratio (A-Weighted, Ref. 50 W, 1 V Input): 106 dB

Analog Frequency Response: 20 Hz–20 kHz (±0.2 dB)

Phonostage: class-A, moving magnet and moving coil

MM Phono Input Impedance: 47 kilohms + 100 pF

Phono Frequency Response (Ref. RIAA Curve): 20 Hz–20 kHz (±1 dB)

DAC: ESS ES9039Q2M

Digital Inputs: USB-C, HDMI eARC, coaxial, optical

Supported Sample Rates (USB-C): 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz

Supported Sample Rates (Other Digital Inputs): 44.1, 48, 88.2, 96, 176.4, 192 kHz

Supported Bit Depths: 16, 24, 32 bit

Digital Frequency Response (Filter 1): 20 Hz–20 kHz (±0.2 dB)

Digital Signal-to-Noise Ratio (A-Weighted, Ref. 50 W, 0 dBFS): 109 dB

Headphone Output (32/300 Ohms): 2.5/5 V RMS

Headphone Load Range: 16–2,000 ohms

Bluetooth Version: 5.4

Bluetooth Profiles and Codecs: A2DP Sink/Source, AVRCP, BLE, SBC, AAC, aptX, aptX HD, aptX Lossless, LE Audio, Auracast

Bluetooth Transmitter Frequency: 2,400–2,483.5 MHz

Bluetooth Transmitter Power: <20 dBm

Mains Voltage: 100 V, 110–120 V, or 220–240 V, 50/60 Hz

Maximum Power Consumption: 700 W

Standby Power Consumption: <0.5 W

Dimensions (H × W × D): 3.9" × 16.97" × 13.54" (99 × 431 × 344 mm)

Weight: 26.46 lb. (12 kg)
