Pathos InControl MkII Preamplifier
The natural partner of the InPower MkII power amp, the InControl MkII is a fully balanced differential design using Tung-Sol ECC803S tubes. It uses the same big, clean VFD display as the InPol series, and the large aluminum volume knob offers 100 steps of high-precision, high dynamic range attenuation. The on-board headphone amp supplies 2 W at 32 ohm to drive most headphones on the market.
Specifications
Tube complement: 2 x Tung-Sol ECC803S
Max input voltage: 4.4 VRMS
Input impedance: 100 kΩ
Output impedance: 110 Ω
Gain: Adjustable 6 dB / 12 dB
Frequency response: 2 Hz - 200 kHz, ±0.5 dB
Inputs
Analog: 2 x balanced XLR, 2 x RCA
Digital (add-on HiDac Mk2 board needed): 2 x USB B, 1 x coaxial S/PDIF, 1 x optical
Outputs: 1 x balanced XLR, 1 x RCA
Headphone
Output power: 3.3 W at 16 Ω, 2 W at 32 Ω
Max output level: 10 VRMS
Dimensions (DWH): 11.4" x 14.1" x 6.1"
Weight: 39.6
